OVP-V8 is a 8 Gigabit network port external transmitter, equal to 4 sending card cascade, cost-effective.The maximum resolution is 5.24 million pixels, and the maximum output of a single network port is 650,000 pixels.
Supports custom resolutions
Flexible loading area, maximum width 3840 pixels , maximum height 3840 pixels
Supports hot backup between network ports
Supports hot backup between transmitters
Hotline：
+86 15921814956Reliable and beautiful structure, convenient installation;
Equal to 4 sending cards in cascade, high cost performance.
The maximum resolutoin is 5.24 million pixels, a single network port support 650,000 pixels maximumly;
Hot backup of display contents is supported between network ports, and hot backup can be supported between transmitters.
Richer display effect;
Firmware update online;
First choice for LED small pitch screens.
| Technical parameters | |
|---|---|
| Status | Launched into market in August , 2023 |
| Control size | Total pixel ≤5 240K;（W≤3840, H≤3840） minimum control size :32x32 |
| Gray scale | ≤65536 |
| Communiction | |
|---|---|
| Receiver | Support full series BX-V receiving card and BX-VMF |
| Communication distance | Category 5 network cable ≤ 140M, Category 6 network cable ≤ 170M Fiber optic cable: single mode transceiver ≤ 20KM, multi mode transceiver ≤ 550M. (Infinite extension using repeaters) |
| transmission equipment | Gigabit fiber optic transceivers and switches |
| Video source input | |
|---|---|
| Video input interface | HDMI |
| Video source frame rate | Standard 60Hz, can automatically adapt to frame rate |
| Input resolution | Supports any input resolution |
| Audio input interface | |
|---|---|
| AUDIO | HDMI audio input, 3.5mm analog audio input interface |
| Gigabit Ethernet port output | |
|---|---|
| Network ports quantity | 8 Gigabit Ethernet ports |
| Lan port splicing | 8 gigabit network port outputs, supporting arbitrary splicing from top to bottom, left to right |
| Lan port load indicator |
The maximum load output is 5.24 million pixels, and the maximum load of a single network port is 650 000 pixels |
| Data transmission format | According to the frame format of a gigabit network, with additional CRC verification |
| Important functions | |
|---|---|
| Parameter Configuration Function | Support |
| Real-time parameter adjustment | Support |
| Brightness Colour Temperature Adjustment | Support |
| Intelligent Detection System | Support |
| Onboard Real Time Clock | Support |
| Multi-screen setting function | Supports simultaneous control of multiple displays of different specifications |
| Background Playback Functions | Support (extended mode) |
| Audio Transfer Function | Support |
| Network BER monitoring | Support |
| System update and maintenance | |
|---|---|
| Platform update | iLEDCloud and iLEDSys update online； Support firmware update online,cost efficient |
| Firmware update |
Support firmware update online,cost efficient |
| Electricity parameters | |
|---|---|
| Working voltage | 100-240VAC 50/60Hz |
| Max power | ≤35 W |
| Environmental adaption | |
|---|---|
| Working temperature | -40℃～80℃ |
| salt-spray resistant level | There is no problem for the distance 500M from sea |
| Electromagnetism compatibility | |
|---|---|
| Wireless harass | Testing for power supply port, LAN and serial port, all reach the standard |
| Immunity of discharging static electricity |
Testing for LAN, serial, USB, sensor, I/O ports. Level 4, discharging 8KV. Reach the standard |
| Surge impact | Testing for power supply port and LAN port. Level 4, discharging voltage is 4KV. |
| Quality assurance | |
|---|---|
| Quality standard | 7*24 hours power-on, fault rate ≤0.3% |
| Construct protection |
Plastic bracket, inflaming retarding, insulation, antiseptic, environmental, anti-static, high temperature resistance |
| Apperance protection | UV three-protection glue for all types, national standard 85 protection level, dust prevention, dampproof, anti-static, salt-spray proof |
